Laminated Air Filter Media Roll G3 G4
Main Features
Filter Grade: Available in G3, G4, M5, M6, F7, F8 and F9, with corresponding MERV ratings from 5 to 14, providing a wide range of filtration options to meet specific air quality needs.
Frame Options: Available in cardboard, aluminum and galvanized steel, allowing flexibility in installation and application.
Low Air Pressure Drop: Designed to minimize air resistance, ensuring efficient airflow and reducing energy costs.
Cost-effective: Durable design extends filter life, reducing replacement frequency and overall maintenance costs.
Standard Sizes: Standard sizes are 610mm x 150m and 510mm x 150m with a thickness of 3mm.
Versatile: Suitable for use as a pre-filter or main filter, depending on the specific requirements of the environment.
application
HVAC Systems: Ideal for commercial and industrial HVAC systems, where maintaining clean air is critical to the health and comfort of occupants.
Automotive and Aerospace Industry: Used in filtration systems in automotive and aerospace applications to ensure clean air quality and protect sensitive components.
Hospitals and Laboratories: Provides the necessary air purity for medical facilities and laboratories to prevent the spread of contaminants and protect patients and sensitive equipment.
Cleanroom Environment: Suitable for the electronics, pharmaceutical and biotechnology industries where stringent air quality standards are required.
Pre-filter or Main Filter: Can be used as a pre-filter to extend the life of finer filters in the system, or as a main filter depending on specific air quality requirements.
Cardboard Frame Thickness Options: Available in 22mm, 44mm and 90mm thicknesses to provide additional customization for a variety of applications.
in conclusion
Laminated air filter media rolls are an excellent solution for maintaining a clean, healthy air environment in a variety of applications. Their rugged design, combined with a range of filtration grades and frame options, make them suitable for commercial, industrial, automotive, healthcare and cleanroom environments. By providing superior filtration efficiency and longer service life, these media rolls help improve air quality and reduce operating costs.
